ZEUS 804X
AMD 530,000
4-CH Low-Impedance 4x800W Power Amplifiers with Crossover
8Ω Stereo Output Power – 800W
4Ω Stereo Output Power – 1200W
8Ω Bridge Output Power – 2500W
Input Sensitivity – 0,775V / 1,2V / 2,5V
Input Impedance – >10KΩ, balanced or unbalanced
Frequency response (1W, 8Ω) – 20Hz-20kHz, +1/-1dB
Power Requirements – 220V – 50/60Hz
Power Consumption (Average/Peak) – 850W/2550W
Input Connectors – 3-Pin Female XLR
Output Connectors – Female Speakon®
Link Connectors – 3-Pin Male XLR
ZEUS X Series is ideal for low-impedance multi-channel installations with power ratings between 200W and 800W RMS @ 8ohm per channel. It is a 4-channel, Class-H series with excellent sound and maximum reliability. It is possible to use in Stereo, Parallel and Bridge mode (CH1-2 / CH3-4).
Each channel integrates a crossover with a low-pass filter, for use with both full-range systems and subwoofers, without the need for external processors. The protection system includes the signal limiter, on-off muting, DC-offset detection, thermal protection, and current limiting. The cooling system is extremely efficient and controls the speed of the two fans in order to ensure excellent noise reduction.
